| MOQ: | 1 pair |
| Price: | USD99~135 per pair |
| Standard Packaging: | 10pcs/plastic bag, 200pcs/carton |
| Delivery Period: | 1-3 work days |
| Payment Method: | L/C, T/T, Western Union |
| Supply Capacity: | 10,000 pcs per month |
10G WDM SFP+ Single Fiber Transceiver Compatible With Cisco Huawei H3C
10G WDM SFP+ Module Single Fiber 1270nm/1330nm 60km SFP Transceiver LC compatible with Cisco/Huawei/H3C
Description:
NuFiber SFP-10G-BX60-SM1270 & SFP-10G-BX60-SM1330 Bi-directional 10Gb/s (SFP+) transceivers are compliant with the current SFP+ Multi-Source Agreement (MSA) Specification. They comply with 10GBASE-ZR/LW Ethernet, SONET OC-192 / SDH and 10G Fiber Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the SFP+ MSA.
Features:
² Supports 9.95Gb/s to 11.3Gb/s bit rates
² Hot-pluggable SFP+ footprint
² Single LC for Bi-directional Transmission
² Maximum link length of 60km
² Built-in 1270/1330 WDM Filter
² Uncooled 1270nm or 1330nm CWDM DFB Laser.
² Power dissipation <1.5W
² No Reference Clock required
² Built-in digital diagnostic functions
² Temperature range 0°C to 70°C
² Very low EMI and excellent ESD protection
² RoHS Compliant Part
Applications:
² 10GBASE-ZR/LW Ethernet
² SONET OC-192 / SDH
² 10G Fiber Channel
Optical Parameters:
|
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Ref. |
|
|
Transmitter |
|||||||
|
Bit Rate |
BR |
9.9 |
|
11.3 |
Gb/s |
|
|
|
Optical Wavelength |
SFP-10G-BX20-SM1270 |
λ |
1260 |
1270 |
1280 |
nm |
|
|
SFP-10G-BX20-SM1330 |
|
1320 |
1330 |
1340 |
|
||
|
Average output power |
Po |
-2 |
|
3 |
dBm |
|
|
|
Optical Extinction Ratio |
ER |
3.5 |
|
|
dB |
|
|
|
Spectral width |
Δλ |
|
|
1 |
nm |
|
|
|
Side Mode Suppression Ratio |
SMSR |
30 |
|
|
dB |
|
|
|
Optical Eye Mask |
|
Compliant with IEEE802.3ae |
|
||||
|
Receiver |
|||||||
|
Bit Rate |
BR |
9.9 |
|
11.3 |
Gb/s |
|
|
|
Optical Wavelength |
SFP-10G-BX20-SM1270 |
λ |
1320 |
1330 |
1340 |
nm |
|
|
SFP-10G-BX20-SM1330 |
|
1260 |
1270 |
1280 |
|
|
|
|
Receiver Sensitivity |
Sen |
|
|
-14.5 |
dBm |
1 |
|
|
Maximum Input Power |
PMAX |
0 |
|
|
dBm |
|
|
|
LOS De-Assert |
LOSD |
|
|
-15 |
dBm |
|
|
|
LOS Assert |
LOSA |
-25 |
|
|
dBm |
|
|
|
LOS Hysteresis |
LOSH |
0.5 |
|
4 |
dB |
|
|
Ordering information:
|
BiDi SFP Transmitter |
||
|
Part Number |
Product Description |
|
|
155Mbp/s SFP Transmitter |
||
|
FE-BX20-SM1310/1550 |
155Mbps,BiDi 1310nm/1550nm SM 20km LC, DDM 0°C~+70°C |
|
|
FE-BX40-SM1310/1550 |
155Mbps, BiDi 1310nm/1550nm SM 40km LC, DDM 0°C~+70°C |
|
|
FE-BX80-SM1310/1550 |
155Mbps, BiDi 1310nm/1550nm SM 80km LC, DDM 0°C~+70°C |
|
|
FE-BX100-SM1310/1550 |
155Mbps, BiDi 1310nm/1550nm SM 120km LC, DDM 0°C~+70°C |
|
|
1.25Gbps SFP Transmitter |
||
|
GE-BX10-SM1310/1550 |
1.25Gbps, BiDi 1310nm/1550nm SM 10km LC,DDM 0°C~+70°C |
|
|
GE-BX20-SM1310/1550 |
1.25Gbps, BiDi 1310nm/1550nm SM 20km LC, DDM 0°C~+70°C |
|
|
GE-BX40-SM1310/1550 |
1.25Gbps, BiDi 1310nm/1550nm SM 40km LC, DDM 0°C~+70°C |
|
|
GE-BX60-SM1310/1550 |
1.25Gbps, BiDi 1310nm/1550nm SM 60km LC, DDM 0°C~+70°C |
|
|
GE-BX80-SM1310/1550 |
1.25Gbps, BiDi 1310nm/1550nm SM 80km LC, DDM 0°C~+70°C |
|
|
GE-BX100-SM1310/1550 |
1.25Gbps, BiDi 1310nm/1550nm SM 120km LC, DDM 0°C~+70°C |
|
|
10Gbps SFP+ Transmitter |
||
|
SFP-10G-BX20-SM1330/1270 |
10Gbps, BiDi 1330nm/1270nm SM 20km LC,DDM 0°C~+70°C |
|
|
SFP-10G-BX40-SM1330/1270 |
10Gbps, BiDi 1330nm/1270nm SM 40km LC,DDM 0°C~+70°C |
|
|
SFP-10G-BX60-SM1330/1270 |
10Gbps, BiDi 1330nm/1270nm SM 60km LC,DDM 0°C~+70°C |
|
|
SFP-10G-BX80-SM1490/1550 |
10Gbps, BiDi 1490nm/1550nm SM 80km LC,DDM 0°C~+70°C |
|
Products Show:
Packing:
Shipping:
Welcome to send us inquiry for this products.
|
|
