SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter

SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter

Product Details:

Place of Origin: China(mainland)
Brand Name: Nufiber
Certification: CE RoHS FCC
Model Number: NF-PSE6301-SFP

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Packing Size/per boxes:21mm*15.6mm*5.3mm 40 Boxes / carton or As Your Mind
Delivery Time: 3~4working day after payment
Payment Terms: T/T, Western Union
Supply Ability: 8000piece/month
Get Best Price Contact Now

Detail Information

Data Rate: 10/100/1000Mbps Fiber Type: SM/MM; SF/DF
Distance: 0-120KM Dimension: 21mm*15.6mm*5.3mm
Material: Iron Case Power: External Power DC52V/0.7A/36W
OEM,ODM: Accept Warranty: 1Years
Wavelength: 850nm/1310nm/1550nm Interface: 1xSFP Slot+1xPOE UTP Port
High Light:

1310nm POE Fiber Media Converter

,

POE Fiber To RJ45 Media Converter

,

FCC POE Powered Switch

Product Description

POE Media Converter 1*10/100/1000M POE RJ45 to 1*100/1000M SFP slot with External power supply DC52V/0.7A/36W





Description:

POE Media converter with 1x10/100/1000Mbps Auto-Negotiation POE RJ45 and 1x100/1000Mbps Fiber SFP port. The products support IEEE802.3af/at power supply standard, maximum output power Up to 25.5 Watts for POE, Plug and Play, no need to convert by software and network protocol,Easy installation and use.Adopt No fan, low power design. Meet the needs of the site and provide a reliable and convenient solution for the network of Ethernet devices for users.The product apply with FCC and CE standards.



Spicification

Standard IEEE802.3i 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3z 1000BASE-TX
IEEE802.3x Flow Control
IEEE802.3af Power over Ethernet
PoE power

15.4W per port (IEEE802.3af)

25.5W per port (IEEE802.3at)

Wiring: Data & power provided over pairs 1/2 and 3/6 or 4/5(+) and 7/8(-)
Cable: UTP cat.5 or higher
Fiber type Multi mode(MM): 62.5/125m.50/125m
Single mode(SM): 9/125m
Distance Multi mode & Dual Fiber 550M
Single mode & Single Fiber:20/40/60/80/120KM
Data rate 10/100/1000Mpbs
Connector 1 RJ45 +1 SC/FC/ST/LC(SFP Slot)
Wavelength 1310nm 1490nm 1550nm
Diagnostic LED Power Link/Activity
Power DC52V/0.7A/36W
Power Consumption <8w
Temperature

0~50℃(Operating)

-20~70℃(Storage)

Humidity 5%~90%
Dimension 90x70x26mm



Features:

1, Support IEEE802.3 10BASE-T;

IEEE802.3i 10Base-T;IEEE802.3u 100Base-TX/FX;

IEEE802.3ab 1000Base-T;IEEE802.3z 1000Base-X; IEEE802.3af; IEEE802.3at;

2, Support 10/100/1000Mbps half-duplex/full-duplex mode and auto MDI/MDIX;

3, Transmission distance:

Multimode(MM): Up to 0.55KM Max;

Singlemode(SM): Up to 120KM Max;

4, POE power pin: 1/2+,3/6- (Option 4/5+,7/8-);

5, RJ45 port support direct and cross automatic recognition function (AUTO-MDIX);

6, Fanless design, its own low heat, work stability and durability stronger;

7, Trouble-free working hours (MTBF)> 50,000 hours, in line with carrier-class operating standards;





Ordering Information

Model Description Fiber Mode Wavelength Distance Connector
NF-PSE5201-C02 10/100Base-Tx to 100Base-FX MMF TRx:850nm 2km SC
or TRx:1310nm
NF-PSE5201-C20 10/100Base-Tx to 100Base-FX SMF TRx:1310nm 20 km SC
NF-PSE5201-C20A/B 10/100Base-Tx to 100Base-FX SMF Tx:1310nm/Rx1550nm 20 km SC
Tx:1550nm/Rx1310nm
NF-PSE5201-SFP 10/100Base-Tx to 100Base-FX SFP 850nm/1310nm/1550nm 0~120km LC/SC
NF-PSE5201G-C02 10/100/1000Base-Tx to 1000Base-FX MMF TRx:850nm 2km SC
or TRx:1310nm
NF-PSE5201G-C20 10/100/1000Base-Tx to 1000Base-FX SMF TRx:1310nm 20 km SC
NF-PSE5201G-C20A/B 10/100/1000Base-Tx to 1000Base-FX SMF Tx:1310nm/Rx1550nm 20 km SC
NF-PSE6301-SFP 10/100/1000Base-Tx to 100/1000Base-FX SFP 850nm/1310nm/1550nm 0~120km LC/SC




Connection Diagram

SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 0



SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 1





Product Show

SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 2SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 3SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 4SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 5





Packing Methods

SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 6

Shipping Methods

SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 7







Factory Show



SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 8



SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 9





FAQ

SFP To UTP POE Fiber Media Converter , POE Fiber To RJ45 Media Converter 10
