Huawei ZTE Compatible SFP+ Optical Cable AOC 1m 5m 850nm 100GbpS To 4x25G
Product Details:
| Place of Origin: | China |
| Brand Name: | NUFIBER |
| Certification: | CE FCC Rohs |
| Model Number: | QSFP28-4SFP28-AxM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | Standard Export Package |
| Delivery Time: | 1-3 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5,000 pcs per month |
|
Detail Information |
|||
| Product Name: | 100G QSFP28 To 4x25G SFP28 AOC | Connector Type: | QSFP28 To SFP28 |
|---|---|---|---|
| Max Data Rate: | 100G To 4x25Gbps | Cable Length: | Customized |
| Temperature: | 0 To 70°C | Optical: | VCSEL Laser |
| High Light: | AOC SFP+ Optical Cable,850nm SFP+ Optical Cable,100GbpS Active Optical Cable |
||
Product Description
100G QSFP28 to 4x25G SFP28 OM3 AOC Active Optical Cable compatible Cisco Huawei HP Mikrotik
Huawei ZTE Compatible 1m 5m 850nm 100GbpS To 4x25G SFP+ Active Optical Cable AOC
Description:
QSFP28 passive copper cable assembly feature eight differential copper pairs, providing four data transmission channels at speeds up to 28Gbps per channel,and meets 100G Ethernet, 25G Ethernet and InfiniBand Enhanced Data Rate(EDR) requirements.Available in a broad rang of wire gages-from 26AWG through 30AWG-this 100G copper cable assembly features low insertion loss and low cross talk.
Designed for applications in the data center,networking and telecommunications markets that require a high speed,reliable cable assembly,this next generation product shares the same mating interface with QSFP+ form factor ,making it backward compatible with existing QSFP ports.QSFP28 can be used with current 10G and 14G applications with substantial signal integrity margin.
Key Features:
| Compatible with IEEE 802.3bj and InfiniBand EDR |
| Supports aggregate data rates of 100Gbps |
| Optimized construction to minimize insertion loss and cross talk |
| Backward compatible with existing QSFP+ connectors and cages |
| Pull-to-release slide latch design |
| 26AWG through 30AWG cable |
| Use active IC to make the limit length of the cable 10M |
| Straight and break out assembly configurations available |
| Customized cable braid termination limits EMI radiation |
| Customizable EEPROM mapping for cable signature |
| RoHS compliant |
Application:
| Switches,servers and routers |
| Data Center networks |
| Storage area networks |
| High performance computing |
| Telecommunication and wireless infrastructure |
| Medical diagnostics and networking |
| Test and measurement equipment |
Mechanical Specifications:
| Length (m) | Cable AWG |
| 1 | 30 |
| 2 | 30 |
| 3 | 30/26 |
| 4 | 26 |
| 5 | 26 |
