XFP-10G-ZR 10G XFP Transceiver , Single Mode Optical Transceiver Modules 120km 1550nm
Product Details:
Place of Origin: | China |
Brand Name: | NuFiber |
Certification: | CE FCC Rohs |
Model Number: | XFP-10G-ZR |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 piece |
---|---|
Packaging Details: | 10pcs/plastic bag, 500pcs/carton |
Delivery Time: | Within 1-3 work days |
Payment Terms: | L/C, T/T, Western Union,Credit Card |
Supply Ability: | 10,000 pcs per month |
Detail Information |
|||
Data Rate: | 10Gb/s | Wavelength: | 1550nm |
---|---|---|---|
Distance: | 120km | Connector: | LC |
DDM: | Support | Fiber Type: | Singlemode Duplex |
Power Supply: | 3.3V | Working Temperature: | 0~70℃ |
Warranty: | 3 Years | Compatibility: | Cisco, HP, Huawei, Finisar... |
Manufacturer: | Yes | ||
High Light: | XFP-10G-ZR 10G XFP Transceiver,10G XFP Transceiver 120km 1550nm,Optical Transceiver Modules 120km 1550nm |
Product Description
10Gb/s XFP Transceiver XFP-10G-ZR dual fiber singlemode 120km 1550nm LC DDM
Description
Nufiber XFP-10G-ZR Small Form Factor 10Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification. The high performance cooled EML transmitter and high sensitivity APD receiver provide superior performance for SONET/SDH and Ethernet applications up to 120km optical links.
Features
- Support multi protocol from 9.95Gb/s to 11.3Gb/s
- Hot pluggable 30 pin connector
- Compliant with XFP MSA
- Transmission distance of 120km over single mode fiber
- 1550nm Cooled EML laser transmitter.
- APD Receiver
- Duplex LC connector
- 2-wire interface for management and diagnostic monitor
- XFI electrical interface with AC coupling
- Power supply voltages : +3.3V, +5V
- Temperature range 0°C to 70°C
- Power dissipation: <3.5W
- RoHS Compliant Part
Applications
- 10GBASE-ZR/ZW Ethernet
- SONET OC-192 / SDH STM-64 ITU-T G.959.1 P1L1-2D2
- 120km 10G LC
- Other optical links
Optical Parameters
Parameter | Symbol | Min | Typ | Max | Unit | Ref. |
Transmitter | ||||||
Operating Date Rate | BR | 9.95 | 11.3 | Gb/s | ||
Bit Error Rate | BER | 10-12 | ||||
Maximum Launch Power | PMAX | 1 | +5 | dBm | 1 | |
Optical Wavelength | λ | 1530 | 1550 | 1565 | nm | |
Optical Extinction Ratio | ER | 8.2 | dB | |||
Spectral Width | Δλ | 1 | nm | |||
Sidemode Supression ratio | SSRmin | 30 | dB | |||
Rise/Fall Time (20%~80%) | Tr/Tf | 35 | ps | |||
Average Launch power of OFF Transmitter | POFF | -30 | dBm | |||
Tx Jitter | Txj | Compliant with each standard requirements | ||||
Optical Eye Mask | IEEE802.3ae | 2 | ||||
Receiver | ||||||
Operating Date Rate | BR | 9.95 | 11.3 | Gb/s | ||
Receiver Sensitivity | Sen | -24 | dBm | 2 | ||
Maximum Input Power | PMAX | -7 | dBm | 2 | ||
Optical Center Wavelength | λC | 1260 | 1600 | nm | ||
Receiver Reflectance | Rrx | -27 | dB | |||
LOS De-Assert | LOSD | -24 | dBm | |||
LOS Assert | LOSA | -34 | dBm | |||
LOS Hysteresis | LOSH | 0.5 | 5 | dB |
Ordering information
Dual Fiber SFP Transceiver | |
Part Number | Product Description |
155Mbp/s SFP Transceiver | |
FE-SX-MM850 | 155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C |
FE-SX-MM1310 | 155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C |
FE-LX20-SM1310 | 155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C |
FE-LX40-SM1310 | 155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C |
FE-LX80-SM1550 | 155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C |
FE-LX120-SM1550 | 155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C |
1.25Gbps SFP Transceiver | |
GE-SX-MM850 | 1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C |
GE-SX-MM1310 | 1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C |
GE-LX20-SM1310 | 1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C |
GE-LX40-SM1310 | 1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C |
GE-LX60-SM1550 | 1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C |
GE-LX80-SM1550 | 1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C |
GE-LX120-SM1550 | 1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C |
10Gbps SFP Transceiver | |
SFP+-10GB-SR | 10G SFP+ SR Multi mode dual fiber LC 850nm 300M |
SFP+-10GB-LRM | 10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M |
SFP+-10GB-LR | 10G SFP+ LR Single mode dual fiber LC 1310nm 20km |
SFP+-10GB-ERM | 10G SFP+ER Single mode dual fiber LC 1310nm 40km |
SFP+-10GB-ER | 10G SFP+ER Single mode dual fiber LC 1550nm 40km |
SFP+-10GB-ZR | 10G SFP+ZR Single mode dual fiber LC 1550nm 80km |
XFP Transceiver | |
XFP-10G-SR | 10G XFP SR Multi mode dual fiber LC 850nm 300M |
XFP-10G-LRM | 10G XFP LRM Single mode dual fiber LC 1310nm 10kM |
XFP-10G-LR | 10G XFP LR Single mode dual fiber LC 1310nm 20km |
XFP-10G-ER | 10G XFP ER Single mode dual fiber LC 1550nm 40km |
XFP-10G-ZR | 10G XFP ZR Single mode dual fiber LC 1550nm 80km |
