Single Fiber LC 10km 25G SFP28 Module Transceiver For Huawei Cisco HP Aruba
Product Details:
Place of Origin: | China |
Brand Name: | NuFiber |
Certification: | CE FCC Rohs |
Model Number: | SFP28-25G-DW10-xx |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 piece |
---|---|
Packaging Details: | 10pcs/plastic bag, 500pcs/carton |
Delivery Time: | Within 1-3 work days |
Payment Terms: | L/C, T/T, Western Union,Credit Card |
Supply Ability: | 10,000 pcs per month |
Detail Information |
|||
Data Rate: | 25Gb/s | Distance: | 10Km |
---|---|---|---|
Connector: | LC | DDM: | Support |
Fiber Type: | Single Mode Duplex LC | Power Supply: | 3.3V |
Working Temperature: | 0~70℃ | Warranty: | 1 Year |
Compatibility: | Huawei, Cisco, HP, H3C... | Manufacturer: | Yes |
High Light: | Single Fiber SFP28 Module Transceiver,LC SFP28 Module Transceiver,Cisco 25G SFP28 Transceiver |
Product Description
SFP28 25G DWDM 10km LC Optical SFP Transceivers For Huawei Cisco HP Aruba Mikrotik
Single fiber LC 10km 25G SFP28 module Transceiver For Huawei Cisco HP Aruba Mikrotik
SFP28 25G DWDM 10Km optical transceiver Compatible Cisco Huawei HP Mikrotik Juniper
Description
The Nufiber SFP-25G-DWDM is a SFP28 transceivers, designed for use in Ethernet links up to 25.78 Gb/s data rate and up to 10 km link length. They are compliant SFF-8472 Rev 12.2b and IEEE 802.3cc, and compatible with SFF-8432a and applicable portions of SFF- 8431 Rev. 3.0c. The product is RoHS compliant and lead-free per Directive 2011/96/EUd.
Features
- Hot-pluggable SFP28 form factor
- Supports 25Gb/s data rate
- 100GHz ITU Grid, C Band
- SMF links up to 10km
- DWDM EML transmitter, PIN photo-detector
- Internal CDR on both Transmitter and Receiver channel
- Duplex LC receptacle
- Single 3.3V power supply
- Power dissipation < 1W
- Digital diagnostics functions are available via the I2C interface
- RoHS-6 compliant
- Commercial case temperature range: 0°C to 70°C
Applications
- 25GBASE-LR Ethernet
Ordering information
Part Number | Rate(bps) | Wave(nm) | Cable Type | Interface | Reach |
Optical Components |
25G SFP28 | ||||||
SFP28-25G-SR | 25G | 850nm | MMF | LC duplex | 100m | VCSEL 850nm |
SFP28-25G-LR | 25G | 1310nm | SMF | LC duplex | 10km | DFB 1310nm |
100G QSFP28 | ||||||
QSFP28-100G-SR4-S | 103.1 Gbp | 850nm | MMF | MTP/MPO-12 | 100m | VCSEL 850nm |
QSFP28-100G-LR4-S | 103.1 Gbp | 1310nm | SMF | LC duplex | 10km | DML 1310nm |
QSFP28-100G-PSM4-S | 103.1 Gbp | 1310nm | SMF | MTP/MPO-12 | 500m | 4x DFB |
QSFP28-100G-SM-SR | 103.1 Gbp | CWDM 1271~1331nm |
SMF | LC duplex | 2km | DML CWDM |
QSFP28-100G-eCWDM4-S | 103.1 Gbp | CWDM 1271~1331nm |
SMF | LC duplex | 10km | DML CWDM |
QSFP28-100G-ER4L-S | 103.1Gbps | 1310nm | SMF | LC Duplex | 25km-40km | 4x EML |
100G CFP/CFP2/CFP4 | ||||||
CFP-100G-SR10 | 103.1 Gbp | 850nm | MMF | MTP/MPO-24 | 150m@OM4, 100m@OM3 | 10x VCSEL |
CFP-100G-LR4 | 103.1 Gbp | 1310nm | SMF | LC duplex | 10km | 4x DFB |
CFP-100G-ER4 | 103.1 Gbp | 1310nm | SMF | LC duplex | 40km | 4x DFB |
CFP2-100G-SR10 | 112Gbps | 850nm | MMF | MTP/MPO | 300m@OM3, 400m@OM4 | 10x VCSEL |
CFP2-100G-LR4-D | 112Gbps | 1310nm | SMF | LC duplex | 10km | 4x DFB |
CFP2-100G-ER4 | 113Gbps | LWDM (1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm) |
SMF | LC duplex | 40km | 4x DFB |
CFP4-100GBASE-LR4 | 112Gbps | 1310nm | SMF | LC duplex | 10km | 4x DFB |
