OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode

Product Details:

Place of Origin: China
Brand Name: NUFIBER
Certification: CE, FCC, RoHS
Model Number: NF-4V1D-T/R-F20

Payment & Shipping Terms:

Minimum Order Quantity: 1 Pair
Packaging Details: 10pair/ carton standard export packing
Delivery Time: 1-3days
Payment Terms: Western Union, T/T,Credit Card.
Supply Ability: 5000 pcs per month
Get Best Price Contact Now

Detail Information

Material: Iron Case Color: Black
High Quality: 3 Years Wavlength: 1310nm/1550nm
Distance: 20KM Fiber Type: Single Fiber Single Mode
Fiber Connector: FC/ST/SC Optional Video: 4Channel BNC
Power Supply: 5VDC OEM & ODM: Accepted
Data: RS485 (RS422 Available)
High Light:

ODM Fiber Video Converter

,

Fiber Video Converter 4BNC 1RS485

Product Description



Fiber Coaxial Video Converter 4BNC 1RS485 1 Fiber Video Transmitter and Receiver for CCTV NF-4V1D-T/R-F20



Description



NuFiberRSeries fiber video multiplexers transmit 4-channel of broadcast quality video using 8-bit digitally encoding and decoding over one multimode or single-mode optical fiber. The modules are directly compatible with NTSC, PAL or SECAM CCTV camera systems. These multiplexer units are typically used in applications that have fixed cameras.

Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required. A typical installation utilizes a 4-channel transmitter unit at the camera end of the link, connected via a single fiber optic cable, to a 4-channel receiver unit at the monitoring end of the link. Devices are available for either standalone or rack mount installation. The units incorporate LED indicators for monitoring the power and video operating status.



Key Features

  • 8-Bit Uncompressed Video Transmission
  • NTSC, PAL or SECAM Video Standards
  • Transmit up to 30km without Optical Attenuation
  • Wide Optical Dynamic Range
  • No EMI, RFI, Cross Talk and Video Distortion
  • Adjustment-free Operation
  • LED indicators Instantly Monitoring System Performance
  •  Standalone or Rack Mount



Specifications



• Video
Video input/output impedance BNC 75 Ω
Number of Channels 4 Channels Video
Video input 1 volt pk-pk (75 ohms)
Bandwidth 5 Hz - 8 MHz
Bit Resolution 8-Bit Digital Transmission
Differential Gain < 1.5%
Differential Phase < 1.5 °
Tilt < 5%
Signal-to-Noise Ratio(SNR) > 67 dB
• Data
Data Format RS485
Bit Error Rate 10E-9
• Electrical & Mechanical
Input Power Requirements DC5V @ 2A
Power Adapter AC 100V~240V
Stand-Alone Dimensions 140*110*25mm
Card for 4U Rack Dimensions 195*140*29mm
• Environmental
Operating Temperature 0°C ~ +70°C
Storage Temperature -20°C ~ +85°C
Relative Humidity 0% ~ 95% (non-condensing)
MTBF >100,000 hours





Products Show

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 0

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 1

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 2

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 3

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 4

Connection Diagram

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 5



Packing &Shipping

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 6

OEM ODM Fiber Video Converter 4BNC 1RS485 Single Fiber Single Mode 7
